Product Details:
Place of Origin: Henan, China
Brand Name: Suny
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: $10,000.00 - $65,000.00/sets
Packaging Details: Wooden cases or plywood boxes for High Efficiency Refine Copper Gold Recovery Scarp PCB Recycling Machine
Supply Ability: 20 Set/Sets per Month

Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best

Description
Condition: New Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: PLC
Warranty: 1 Year Power (kW): 75
Weight (KG): 15000 Key Selling Points: High Productivity
Applicable Industries: Manufacturing Plant, Recycling Machine, Manufacturing Plant,Recycling Machine Showroom Location: Egypt, Canada, United States, Thailand, Chile
Name: Scrap PCB Recycling Machine Electronic Waste Equipment Raw Material: Electronic Waste, Computer Boards, TV Boards, Smartphone Boards, Etc
Capacity: 300-1000kg/h Final Products: Copper And Resin Powder
Recover Rate: 99% And Above Separating Method: Air Flow Separator
Environment: Cyclone Dust Collector After-sales Service Provided: Video Technical Support,Field Installation,
Port: Qingdao

WASTE PCB RECYCLING PLANT
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 0
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 1


PRODUCT APPLICATION


Waste PCB Recycle Plant is used to recycle all kinds of Printed Circuit boards, such as the computer boards, cell phone boards, TV boards, copper-clad laminate, and other household appliances, and the separation of leftover material of the mixed metal and nonmetal materials.
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 2


FINAL PRODUCTS


Because of the high value of the metals, fiber and resin, there is no doubt that this plant not only help to change waste into treasure, but also bring great economic benefits.Through years of practice and theoretical analysis, we obtain the best separation result, the separating purity can be reached to 99%.
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 3
TECHNICAL PARAMETERS
Model
ZYPCB-300
ZYPCB-500
ZYPCB-1000
Capacity
300 Kg/H
500 Kg/H
1000 Kg/H
Power
102 Kw
134 Kw
194 Kw
Weight
15 Ton
20 Ton
30 Ton
Dimension (m)
20*5*5
25*6*5
30*6*5

NOTE:

Working Voltage:380V, 415V ,440V or can be customized.
(If you want more detailed parameters and quotations, please contact us)


PRODUCT STRUCTURE


The Waste PCB Recycle Plant consists of shredding system, milling system, sorting system and dust collection system, the whole process is controlled by PLC.
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 4
The first crushing machine we choose the double shafts shredder, and the second crushing machine we use the hammer crusher, and the third crushing machine we use the high speed turbine grinding machine, the material after shredding, crushing and grinding will be separated by the air separator and the electrostatic separator.
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 5


PRODUCT FEATURES


The Waste PCB Recycle Plant adopts PLC control system, suitable structure and layout, stable performance and low noise;

Dual Crushing System Ensures the Uniformity of Particle Sizes
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 6

Feeding with Negative Pressure Principle Ensures No Dust Pollution
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 7

Dual Sorting System Ensures a 99% Metal Separation Rate
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 8

Pulse Dust Removal Equipment Ensures the Cleanness in the Workshop
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 9
RELATED CONFIGURATION
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 10
CUSTOMER SITE
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 11
CUSTOMER VISITING
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 12
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 13
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 14
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 15
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 16
Air Flow Separator Refine Copper Gold Recovery Scarp PCB Recycling Machine with Best 17
